Specifications | ||
1 | Operating weight | 8100kg |
2 | Standard bucket capacity | 0.37m3 |
3 | Arm length | 1730mm |
4 | Boom length | 3904mm |
Engine | ||
1 | Model | Yanmar 4TNV98T-SFN |
2 | Type | Turbo-charged |
3 | Power | 53.1KW/2200rpm |
4 | Max. torque | 312.7N.m |
5 | No. of cylinders | 4 |
6 | Displacement | 3.319L |
Dimensions | ||
1 | Overall length | 6450mm |
2 | Overall width | 2210mm |
3 | Overall height of boom | 2615mm |
4 | Width of platform | 2210mm |
5 | Overall height of cab | 2615mm |
6 | Ground clearance of counterweight | 785mm |
7 | Min.ground clearance | 370mm |
8 | Rear swing radius | 1980mm |
9 | Track wheel base distance | 2200mm |
10 | Chassis length | 2835mm |
11 | Chassis width | 2090mm |
12 | Track gauge | 1640mm |
13 | Standard width of track shoe | 450mm |
Working Range | ||
1 | Max. digging reach | 6675mm |
2 | Max. digging depth | 4245mm |
3 | Max. vertical wall digging depth | 3945mm |
4 | Max. digging height | 7120mm |
5 | Max. dumping height | 4985mm |
6 | Min.swing radius | 2140mm |
Hydraulic system | ||
1 | Main pump | |
Type | Variable displacement axial piston pump | |
Max. displacement | 90ML | |
Working pressure | 27.5Mpa | |
2 | Hydraulic motor | |
Swing | Fixed displacement axial piston motor | |
Travel | Variable displacement axial piston motor | |
Performance | ||
1 | Swing speed | 12rpm |
2 | Max. travel speed H/L | 4.5/2.5km/h |
3 | Gradeability | 30° |
4 | Max. digging force of bucket | 53kN |
5 | Max. digging force of arm | 44kN |
6 | Ground pressure | 37Kpa |
Tank capacity | ||
1 | Fuel tank capacity | 138L |
2 | Hydraulic tank capacity | 95L |
