Specifications | ||
1 | Operating weight | 24800kg |
2 | Standard bucket capacity | 1.2m3 |
3 | Arm length | 3050mm |
4 | Boom length | 5850mm |
Engine | ||
1 | Model | CUMMINS 6BTAA5.9-C178 |
2 | Type | Turbo-charged with inter-cooled |
3 | Power | 133KW/2000rpm |
4 | Max. torque | 708N.m at 1500rpm |
5 | No. of cylinders | 6 |
6 | Displacement | 5883cc |
Dimensions | ||
1 | Overall length | 9840mm |
2 | Overall width | 3180mm |
3 | Overall height of boom | 3180mm |
4 | Width of platform | 2700mm |
5 | Overall height of cab | 2999mm |
6 | Ground clearance of counterweight | 1139mm |
7 | Height of engine cover | 2436mm |
8 | Min.ground clearance | 480mm |
9 | Length of platform | 2870mm |
10 | Rear swing radius | 2940mm |
11 | Track wheel base distance | 3830mm |
12 | Chassis length | 4640mm |
13 | Chassis width | 3180mm |
14 | Track gauge | 2580mm |
15 | Standard width of track shoe | 600mm |
Working Range | ||
1 | Max. digging reach | 10260mm |
2 | Max. digging reach at groud level | 10080mm |
3 | Max. digging depth | 7000mm |
4 | Max. digging depth on ground | 6815mm |
5 | Max. vertical wall digging depth | 6090mm |
6 | Max. digging height | 9620mm |
7 | Max. dumping height | 6676mm |
8 | Min.swing radius | 3740mm |
Hydraulic system | ||
1 | Main pump | |
Type | Variable displacement axial piston pump | |
Max. displacement | 2×112cc/rev C TYPE:2×115CC/rev | |
Working pressure | 32.3/34.3Mpa C TYPE:32.3/34.3Mpa | |
2 | Hydraulic motor | |
Swing | Fixed displacement axial piston motor | |
Travel | Fixed displacement axial piston motor | |
Performance | ||
1 | Swing speed | 11.3rpm C TYPE:11.5rpm |
2 | Max. travel speed H/L | 5.3/3.5km/h C TYPE:5.4/3.6km/h |
3 | Gradeability | 35° |
4 | Traction | 184797N C TYPE:191614N |
5 | Max. digging force of bucket | 16200kgf |
6 | Max. digging force of arm | 12300kgf |
7 | Ground pressure | 45kpa |
Tank capacity | ||
1 | Fuel tank capacity | 400L |
2 | Hydraulic tank capacity | 210L |
