Specifications | ||
1 | Operating weight | 32500kg |
2 | Standard bucket capacity | 1.45m3 |
3 | Width of track shoes | 600mm |
Engine | ||
1 | Model | CUMMINS 6CTAA8.3 |
2 | Type | Turbo-charged with inter-cooled |
3 | Power | 186KW/2200rpm |
Working Range | ||
1 | Max. digging reach | 11110mm |
2 | Max. digging depth | 7110mm |
3 | Max. vertical wall digging depth | 6480mm |
4 | Max. digging height | 10210mm |
5 | Max. dumping height | 7110mm |
6 | Min.swing radius | 4310mm |
Dimensions | ||
1 | Overall length | 11140mm |
2 | Overall width | 3280mm |
3 | Overall height of boom | 3280mm |
4 | Width of platform | 2995mm |
5 | Overall height of cab | 3130mm |
6 | Ground clearance of counterweight | 1220mm |
7 | Min.ground clearance | 500mm |
8 | Length of platform | 3405mm |
9 | Rear swing radius | 3450mm |
10 | Track wheel base distance | 4050mm |
11 | Chassis length | 4940mm |
12 | Chassis width | 3280mm |
13 | Track gauge | 2680mm |
14 | Standard width of track shoe | 600mm |
Hydraulic system | ||
1 | Main pump | |
Type | Variable displacement axial piston pump | |
Max flow | 2×140cc/rev | |
Main safety valve adjusted power | 32.3/34.3Mpa(kg) | |
2 | Hydraulic motor | |
Swing | Fixed displacement axial piston motor | |
Travel | Variable displacement axial piston motor | |
Performance | ||
1 | Swing speed | 9.7rpm |
2 | Travel speed H/L | 5.4/3.2km/h |
3 | Gradeability | 35° |
4 | Max. digging force of bucket | 210KN |
5 | Max. digging force of arm | 161KN |
6 | Ground pressure | 53Kpa |
